All Wave Super BF-361

All Wave Super BF-361; RCA RCA Victor Co. (ID = 2415896) Radio
All Wave Super BF-361; RCA RCA Victor Co. (ID = 2415153) Radio All Wave Super BF-361; RCA RCA Victor Co. (ID = 2415175) Radio
Use red slider bar for more.
All Wave Super BF-361; RCA RCA Victor Co. (ID = 2415153) Radio
RCA RCA Victor Co.: All Wave Super BF-361 [Radio] ID = 2415153 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model All Wave Super BF-361, RCA (RCA Victor Co. Inc.); New York (NY):
Cliente: Espósito

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1961 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12AV6 12BD6 12BE6 30A5 12Z-E8 35W4
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: All Wave Super BF-361 - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 480 x 200 x 160 mm / 18.9 x 7.9 x 6.3 inch
Literature/Schematics (1) -- Schematic

Model page created by Carlos A. Pieroni-García. See "Data change" for further contributors.
