For model M60 Ch= RC357K, RCA (RCA Victor Co. Inc.); New York (NY):
Data taken from RCA Service Notes

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 6: 6K7 6A8 6K7 6Q7 6K6GT 0Z4G
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / =6 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
Power out 2 W (unknown quality)
from Radiomuseum.org Model: M60 Ch= RC357K - RCA RCA Victor Co. Inc.; New
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 6 x 6 x 10.75 inch / 152 x 152 x 273 mm
Notes Vibrator for +B.
Price in first year of sale 29.95 USD
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 10 = 1939 and before
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series
