45-W-9 Ch= RC-1095A

RCA (RCA Victor Co. Inc.); New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1949–1951
perfect model
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 53444
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 9
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)     8 FM circuit(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 115 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
  • Power out
  • 10 W (11 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 45-W-9 Ch= RC-1095A - RCA RCA Victor Co. Inc.; New
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 29.25 x 32 x 19.75 inch / 743 x 813 x 502 mm
  • Notes

  • The RCA 45-W-9 is an AC operated combination automatic phonograph and BC/FM band receiver.  The turntable is a 45 RPM model RP-190-2, which holds up to twelve 7 inch fine groove records.  Has push-pull output stage.  Has built-in AM and FM antenna's, with provision for connecting external AM and/or external FM antenna.  Cabinet was available in Mahogany, Walnut or Oak.

    The BC band frequency range is 540 to 1600kHz.  The FM band frequency range is 88 to 108MHz.  Uses Qty(3) #51 lamps, two for the dial and one for the jewel.

  • Net weight (2.2 lb = 1 kg)
  • 90 lb (90 lb 0 oz) / 40.860 kg
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 21, Copyright 1950
