For model U129 Ch= RC-335K, RCA (RCA Victor Co. Inc.); New York (NY):
Image Courtesy of Mark V. Stein for Radiomuseum.org use only.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6A8 6J7 6K7 6H6 6U5 6F5 6F5 6F6G 6F6G 5U4G
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 10 W (unknown quality)
from Radiomuseum.org Model: U129 Ch= RC-335K - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 33.3 x 35 x 17 inch / 846 x 889 x 432 mm
Notes

Motorized tuning.
This model has 5 power supply ratings:
Rating A...105-125V, 50-60 Cycles
Rating A6...105-125V, 60 Cycles
Rating B2...105-125V, 25 Cycles
Rating C...105-130;140-160;200-250V, 50-60 Cycles
Rating C6...105-130;140-160;200-250V, 60 Cycles

Net weight (2.2 lb = 1 kg) 104 lb (104 lb 0 oz) / 47.216 kg
Price in first year of sale 185.00 $
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 10 = 1939 and before
Mentioned in Guide to Old Radios
Literature/Schematics (1) Pre-War Consoles (and Bunis/Slusser)
Literature/Schematics (2) RCA Victor Service Notes "Red Book" Series
Literature/Schematics (3) Radio Retailing (Radio & Television R.) (February 1939 page 30)
