- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1934
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 52965
-
- alternative name: RCA Manufacturing || Victor Talking Machine
From E-BAY
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 460 kHz
- Wave bands
- Broadcast, Long Wave and more than two Short Wave bands.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110, 125, 210, 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 341 Duo - RCA RCA Victor Co. Inc.; New
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 31.125 x 40 x 19.5 inch / 791 x 1016 x 495 mm
- Notes
- Covers 140 kc to 18000kc in four bands. Turntable speed: 33rpm and 78rpm.
- Price in first year of sale
- 250.00 USD
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 5 = ca. 1934 and before
- Mentioned in
- Pre-War Consoles
- Literature/Schematics (1)
- Collector's Guide to Antique Radios (6th edition)
- Literature/Schematics (2)
- RCA Victor Service Notes "Red Book" Series
