RC-427 Radio chassis

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978170) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978171) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978172) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978173) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978174) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978175) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978176) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978177) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978178) Radio

RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978179) Radio
Use red slider bar for more.
RC-427 Radio chassis; RCA RCA Victor Co. (ID = 978170) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 11: 6K7 6A8 6K7 6J7 6U5 6K7 6R7 6J5 6J5 6F6 6F6
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Tuned circuits 9 AM circuit(s)
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 10 W (unknown quality)
from Radiomuseum.org Model: RC-427 Radio chassis - RCA RCA Victor Co. Inc.; New
Material Metal case
Shape Chassis only or for «building in»
Notes part of 12"TV-combination TRK-12; needs SPU RS-83E.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 10 = 1939 and before
