SHF2 Ch= RC-1180A & RS-147E
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1958 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 181084
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Sams Photofact Folders reference picture.
tuner and turntable from rear
Amplifier 4 parallel 6V6GTs in push pull
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- 6CB6 6J6 6BA6 6AU6 6AL7GT 6AU6 6AL5 6AV6 6CG7 12AU7A 6AU6 6AU6 6V6GT 6V6GT 6V6GT 6V6GT 5U4GB
- Number of Transistors
- 1
- Semiconductors
- 2N104
- Main principle
- Superhet with RF-stage; ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120 Volt
- Loudspeaker
- 4 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: SHF2 Ch= RC-1180A & RS-147E - RCA RCA Victor Co. Inc.; New
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
- Chassis RC-1180A is an AM/FM Tuner and Chassis RS-147E is the Power Amplifier.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 7-58, Set 405, Folder 12)
