Radiola Super-VIII (8)

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 242917) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028153) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028154) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028155) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028156) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028157) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028158) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028159) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028160) Radio

Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1028161) Radio
Radiola Super-VIII ; RCA RCA Victor Co. (ID = 394709) Radio Radiola Super-VIII ; RCA RCA Victor Co. (ID = 394706) Radio
Radiola Super-VIII ; RCA RCA Victor Co. (ID = 394710) Radio Radiola Super-VIII ; RCA RCA Victor Co. (ID = 394707) Radio
Radiola Super-VIII ; RCA RCA Victor Co. (ID = 394708) Radio Radiola Super-VIII ; RCA RCA Victor Co. (ID = 917026) Radio
Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1141751) Radio Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1164850) Radio
Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1260316) Radio Radiola Super-VIII ; RCA RCA Victor Co. (ID = 1278165) Radio
Use red slider bar for more.
Radiola Super-VIII ; RCA RCA Victor Co. (ID = 394709) Radio
RCA RCA Victor Co.: Radiola Super-VIII [Radio] ID = 394709 380x583
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiola Super-VIII (8), RCA (RCA Victor Co. Inc.); New York (NY):
Ebay Nr. 260186050071 Bild bearbeitet.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1924 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UV199 UV199 UV199 UV199 UV199 UV199 or UX120
Main principle Superheterodyne (common); Special type of reception - please describe.
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries
Loudspeaker Horn
Power out
from Radiomuseum.org Model: Radiola Super-VIII - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with any shape - in general
Notes The "RCA Radiola Super-VIII is a six-tube dry battery operated Super-heterodyne, utilising a new principle - the Second Harmonic Oscillator - simplified for everybody's operation." This is a statement from a small "Radio Catalogue R-7" from 1924, made by Juius Andrae & Sons Co. Milwaukee, Wisconsin. Built in frame aerial. There is also a table model with the same schematic, called "Radiola Super-Heterodyne".
Price in first year of sale 425.00 $
External source of data Ernst Erb
Source of data Guide to Old Radios
Circuit diagram reference Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)
Mentioned in Radio Manufacturers of the 1920's, Vol. 3
Literature/Schematics (1) Radio Broadcast, Mar. 1924. p. 443
