- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1938 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295374
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 105 to 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 97E - RCA Victor International,
- Shape
- Console: Chairside Radio.
- Notes
-
The Canadian RCA-Victor model 97E is a 7-tube chairside radio with pushbutton tuning and tuning eye tube. Covers standard broadcast and shortwave. May be similar to USA model 97E except for tube types.
- Literature/Schematics (1)
- - - Manufacturers Literature (RCA Service Manual (Montreal, Canada))
