For model A25, RCA Victor (International), Montreal

Country:  Canada
Manufacturer / Brand:  RCA Victor (International), Montreal
Year: 1941/1942 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6SK7 6SA7 6SK7 6SQ7 6U5 6F6G 5Y4G
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: A25 - RCA Victor International,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 22 x 13 x 10.5 inch / 559 x 330 x 267 mm
Notes RCA Victor A25 and A38 share the same schematics with CGE KL-70 and KL-76.
Price in first year of sale 99.95 CAD
Source of data -- Original prospect or advert
Circuit diagram reference Radio College of Canada
Mentioned in CGE Sheet 74

Model page created by Ashis Mukerjea. See "Data change" for further contributors.
