RCA Victor: A5 [Radio] ID = 1604118 933x802
Select picture or schematic to display from thumbnails on the right and click for download.
For model A5, RCA Victor (International), Montreal:
From a Kijiji advertisement.

Country:  Canada
Manufacturer / Brand:  RCA Victor (International), Montreal
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6SA7 6SK7 6SQ7 6U5 6F6G 5Y4G
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: A5 - RCA Victor International,
Material Wooden case
Shape Tablemodel with Push Buttons.
Source of data -- Original-techn. papers.
Mentioned in Volume 1939-1940 page 17

Model page created by Ashis Mukerjea. See "Data change" for further contributors.
