A-36

A-36 ; RCA Victor (ID = 599692) Radio

A-36 ; RCA Victor (ID = 599694) Radio

A-36 ; RCA Victor (ID = 599695) Radio

A-36 ; RCA Victor (ID = 599696) Radio

A-36 ; RCA Victor (ID = 599697) Radio

A-36 ; RCA Victor (ID = 599698) Radio
A-36 ; RCA Victor (ID = 1049503) Radio A-36 ; RCA Victor (ID = 1049507) Radio
A-36 ; RCA Victor (ID = 599691) Radio A-36 ; RCA Victor (ID = 1049504) Radio
A-36 ; RCA Victor (ID = 1049505) Radio A-36 ; RCA Victor (ID = 1049506) Radio
A-36 ; RCA Victor (ID = 1049508) Radio A-36 ; RCA Victor (ID = 1368450) Radio
A-36 ; RCA Victor (ID = 1368452) Radio A-36 ; RCA Victor (ID = 2179263) Radio
Use red slider bar for more.
A-36 ; RCA Victor (ID = 1049503) Radio
RCA Victor: A-36 [Radio] ID = 1049503 600x800
Select picture or schematic to display from thumbnails on the right and click for download.
For model A-36, RCA Victor (International), Montreal:
Picture of a RCA Victor model A-36 taken from montreal.kijiji.ca Ad ID 306360434 Grill cloth appears to not be original.

Country:  Canada
Manufacturer / Brand:  RCA Victor (International), Montreal
Year: 1941/1942 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6SA7 6SK7 6SQ7 6F6G 5Y4G
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: A-36 - RCA Victor International,
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 25.75 x 35.5 x 11.75 inch / 654 x 902 x 298 mm
Price in first year of sale 89.95 CAD
Source of data -- Original-techn. papers.
Mentioned in RCA Volume 3 page 27
Literature/Schematics (1) Pre-War Consoles

Model page created by Ashis Mukerjea. See "Data change" for further contributors.



All listed radios etc. from RCA Victor (International), Montreal
Here you find 616 models, 386 with images and 571 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
