RCA Victor: B61 [Radio] ID = 2236936 407x382
Select picture or schematic to display from thumbnails on the right and click for download.
For model B61, RCA Victor (International), Montreal:
From service manual.

Country:  Canada
Manufacturer / Brand:  RCA Victor (International), Montreal
Year: 1939 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 1R5 1N5G 1N5G 1H5G 1A5G 1G6G
Conflicting model year with tubedata.
The model date contradicts tube dates. [ 1R5 (1940)]
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 9 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 1.5 & 2 x 45 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out 0.55 W (0.65 W max.)
from Radiomuseum.org Model: B61 - RCA Victor International,
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 16.4 x 11.5 x 7.6 inch / 417 x 292 x 193 mm
Notes

The RCA Victor model B61 is a 6-tube battery powered table radio. Covers the following ranges:

Range Frequency
Broadcast 540-1720 kHz
MW 3.0-9.5 MHz
SW1 9.5-11.7 MHz
SW2 11.7-15.1 MHz
SW3 15.1-22.5 MHz



Literature/Schematics (1) RCA Service Manual Vol 2 P. 203

Model page created by Tom Seeger. See "Data change" for further contributors.
