• Year
  • 1936 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 295213

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 460 kHz; 3 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Storage and/or dry batteries / 1.5 & 2.5 & 4.5 & 7.5 & 90 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: BT6-1 - RCA Victor International,
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • The Canadian RCA-Victor model BT6-1 is a 6-tube battery powered table radio. Covers standard broadcast and shortwave. Requires an external wire antenna.

  • Literature/Schematics (1)
  • - - Manufacturers Literature (RCA Victor Service Manual (Montreal, Canada))
  • Author
  • Model page created by Tom Seeger. See "Data change" for further contributors.
