- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1941
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 228490
RCA Proscpectus B-5002-7-41
RCA Proscpectus B-5002-7-41
1939-8-41 Pricelist
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios)
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
- Power out
- 1.5 W (3 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Clipper - RCA Victor International,
- Shape
- Chassis only or for «building in»
- Notes
-
Four pushbuttons, AVC. Vibrator for B+. For positive ground only.
- Price in first year of sale
- 49.00 CD$
- Mentioned in
- RCA Prospectus B-5002-7-41, 1939-8-41 Pricelist
- Literature/Schematics (1)
- RCA Service Manual Vol 4 P. 275-280
- Author
- Model page created by Adalbert Gebhart. See "Data change" for further contributors.
