Little Master I & II Wood Cabinet

RCA Victor (International), Montreal

  • Year
  • 1947/1948
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 182699

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • AC/DC-set / 105 to 125 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 0.75 W (1.5 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Little Master I & II [Wood Cabinet] - RCA Victor International,
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 303 x 195 x 160 mm / 11.9 x 7.7 x 6.3 inch
  • Notes
  • Built in loop antenna. Terminal for external antenna. Sliderule dial.

    The Canadian RCA Victor model Little Master I and II are 5-tube table radios for broadcast reception. Has a 4 x 6 inch eliptical speaker and internal loop antenna. It was available in ivory and brown coloured plastic cabinet.

  • Circuit diagram reference
  • Radio College of Canada
  • Literature/Schematics (1)
  • Canada schematics RCA Victor page 98
  • Literature/Schematics (2)
  • RCA Service Manual Vol 4 P. 283-284
  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
