• Country
• Canada

• Manufacturer / Brand
• RCA Victor (International), Montreal

• Year
• 1952/1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 276748

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AV6 50C5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Power out
• 1 W (1.5 W max.)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Nipper III - RCA Victor International,

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 10 x 6 x 4.5 inch / 254 x 152 x 114 mm

• Author
• Model page created by Jean Marcotte. See "Data change" for further contributors.

• Other Models

• Here you find 667 models, 437 with images and 606 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
