- Country
- Canada
- Manufacturer / Brand
- RCA Victor (International), Montreal
- Year
- 1939/1940
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 148920
Taken from RCA Service Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Power out
- 3.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Q22C - RCA Victor International,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 16 x 10.75 x 7.5 inch / 406 x 273 x 191 mm
- Net weight (2.2 lb = 1 kg)
- 9.1 kg / 20 lb 0.7 oz (20.044 lb)
- Source of data
- -- Original-techn. papers.
- Mentioned in
- Volume 1939-1940 page 59
- Author
- Model page created by Ashis Mukerjea. See "Data change" for further contributors.
