Voltohmyst WV-77-E (K)

RCA (RCA Victor Co. Inc.); New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1959 ?
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 137155
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 2
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 105-125 & 1.5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Voltohmyst WV-77-E - RCA RCA Victor Co. Inc.; New
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 5.63 x 7.75 x 4.75 inch / 143 x 197 x 121 mm
  • Notes

  • RCA WV-77E(K), Voltohmyst; Factory wired US$ 46.95 or as Kit US$ 29.95.

  • Source of data
  • -- Original prospect or advert
  • Mentioned in
  • RCA Test Equipment and Accessories ~1965
  • Literature/Schematics (1)
  • Radio News (January 1959)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model Voltohmyst is part of the collections of the following members.

 Forum

Forum contributions about this model: RCA RCA Victor Co.: Voltohmyst WV-77-E

Threads: 1 | Posts: 6

I have purchased an RCA Model WV77-E, Voltohmyst via online auction. Although I have not received the unit yet, the seller states that the ohms function is "off." Searching the manual, I find information on how to calibrate for correct voltage readings, but no calibration instruction is given for the resistance function. I was hoping to be be forearmed with a bit information about what to check on the ohms function of this meter by the time it arrives later this week.

(Of course I will inspect the battery terminals and replace the battery, first.)

Thank you.

Rob

Rob Tracy, 17.Sep.13
