• Country
• Italy

• Manufacturer / Brand
• RCF; Reggio Emilia (AEB Industriale s.r.l., dBtechnologies)

• Year
• 1973 ??

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 233652

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• unknown_Tube EL503 EL503

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 30 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: AM20 - RCF; Reggio Emilia AEB

• Shape
• Tablemodel, low profile (big size).

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.

• Other Models

• Here you find 85 models, 85 with images and 53 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
