• Country
• Italy

• Manufacturer / Brand
• RCF; Reggio Emilia (AEB Industriale s.r.l., dBtechnologies)

• Year
• 1970 ??

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 182974

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• BC107 BC107 BC107 BC107 40251 BC142 BC142 40251 40251 40251

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 35 W (45 W max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: AM-835 - RCF; Reggio Emilia AEB

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 318 x 120 x 214 mm / 12.5 x 4.7 x 8.4 inch

• Notes
• Amplificatore audio con 35 Watt musicali e 50 Watt di picco. Ingressi per 2 microfoni, ingresso Tape e ingresso Fono. Regolazione volume unico per i 2 microfoni, regolatore volume unico per Tape/fono, regolatore di tono.

• Net weight (2.2 lb = 1 kg)
• 8.4 kg / 18 lb 8 oz (18.502 lb)

• Literature/Schematics (1)
• Manuale di Servizio - RCF

• Author
• Model page created by Salvatore Baldi † 2017. See "Data change" for further contributors.
