For model Cameo ABX, Cameo (Gordon Elf Ltd); 78 Rathbone Place, London W1:
Cameo ABX

Country:  Great Britain (UK)
Manufacturer / Brand:  Cameo (Gordon Elf Ltd); 78 Rathbone Place, London W1
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: TH233 EF9 EBC3 Pen383 CY1
Main principle Super-Heterodyne (Super in general); ZF/IF 430 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 100-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Cameo ABX - Cameo Gordon Elf Ltd; 78
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes Transportable model, but not a "Portable" (cordless operable) radio.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (455)

Model page created by Keith Staines. See "Data change" for further contributors.



All listed radios etc. from Cameo (Gordon Elf Ltd); 78 Rathbone Place, London W1
Here you find 2 models, 2 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
