• Country
• Great Britain (UK)

• Manufacturer / Brand
• Regentone Products / Radio Television; Romford, Isleworth, London

• Year
• 1953/1954

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 101809

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECH42 EAF42 EBC41 EL41 EZ40

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 220-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: A133 - Regentone Products / Radio

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 500 x 340 x 200 mm / 19.7 x 13.4 x 7.9 inch

• External source of data
• Malcolm Bennett

• Author
• Model page created by Günther Stabe † 19.8.20. See "Data change" for further contributors.
