• Country
• Switzerland

• Manufacturer / Brand
• Resonar (Marke / marque / marca /brand)

• Year
• 1966/1966

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 74601

• • alternative name: Rediffusion AG; Zürich

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECC85 ECH81 EF89 EF85 EMM803 ECC808 EL84 EL84

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player (not changer); WiredWirelessReceiver (AF or RF)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 6639USG - Resonar Marke / marque / marca

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 660 x 354 x 325 mm / 26 x 13.9 x 12.8 inch

• Notes
• NF-Stereo, Phono Dual 410, Anschlüsse für FM-Stereo-Multiplexer, HF-TR, NF-TR, TB, Zusatz-LS, 2 Skalalampen 6,3V/0,3A. Herstellung Biennophone (Fa. Velectra, Biel), Vertrieb Rediffusion Zürich, Chassis gleich wie Biennophone "Bernina-Stereo 10HH".

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Herbert Odermatt † 26.Nov.05. See "Data change" for further contributors.
