Bambino-Superior

Bambino-Superior ; Rex-Plastic, Max (ID = 514621) Kit
Bambino-Superior ; Rex-Plastic, Max (ID = 704024) Kit Bambino-Superior ; Rex-Plastic, Max (ID = 704025) Kit
Bambino-Superior ; Rex-Plastic, Max (ID = 704026) Kit Bambino-Superior ; Rex-Plastic, Max (ID = 514618) Kit
Bambino-Superior ; Rex-Plastic, Max (ID = 514619) Kit Bambino-Superior ; Rex-Plastic, Max (ID = 194369) Kit
Bambino-Superior ; Rex-Plastic, Max (ID = 514620) Kit
Use red slider bar for more.
Bambino-Superior ; Rex-Plastic, Max (ID = 704024) Kit
Rex-Plastic, Max: Bambino-Superior [Kit] ID = 704024 900x708
Select picture or schematic to display from thumbnails on the right and click for download.
For model Bambino-Superior, Rex-Plastic, Max Ernst KG.; Nürnberg:
Abgebrochener Schriftzug rechts - etwa passend - ergänzt

Country:  Germany
Manufacturer / Brand:  Rex-Plastic, Max Ernst KG.; Nürnberg
Year: 1960 ? Category: Kit (Parts plus instruction) or building instructions only
Semiconductors (the count is only for transistors) 3: OC44 OC71 OC74 OA70
Main principle TRF without regeneration; 2 AF stage(s); Reflex
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out
from Radiomuseum.org Model: Bambino-Superior - Rex-Plastic, Max Ernst KG.;
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 135 x 95 x 80 mm / 5.3 x 3.7 x 3.1 inch
Notes Bausatz.
Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
External source of data E. Erb 3-907007-36-0
Source of data - - Data from my own collection / Radiokatalog Band 2, Ernst Erb


All listed radios etc. from Rex-Plastic, Max Ernst KG.; Nürnberg
Here you find 14 models, 11 with images and 8 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
