M5A

M5A; Roberts Radio Co.Ltd (ID = 1258676) Radio

M5A; Roberts Radio Co.Ltd (ID = 1258677) Radio

M5A; Roberts Radio Co.Ltd (ID = 1258678) Radio
M5A; Roberts Radio Co.Ltd (ID = 1885690) Radio M5A; Roberts Radio Co.Ltd (ID = 1885691) Radio
M5A; Roberts Radio Co.Ltd (ID = 1885692) Radio M5A; Roberts Radio Co.Ltd (ID = 1885693) Radio
M5A; Roberts Radio Co.Ltd (ID = 1885694) Radio M5A; Roberts Radio Co.Ltd (ID = 1885695) Radio
M5A; Roberts Radio Co.Ltd (ID = 1885696) Radio M5A; Roberts Radio Co.Ltd (ID = 1885697) Radio
M5A; Roberts Radio Co.Ltd (ID = 211737) Radio
Use red slider bar for more.
M5A; Roberts Radio Co.Ltd (ID = 1885690) Radio
Roberts Radio Co.Ltd: M5A [Radio] ID = 1885690 1178x1548
Select picture or schematic to display from thumbnails on the right and click for download.
For model M5A, Roberts Radio Co.Ltd., East Molesey, Surrey, UK:
Courtesy by Han Bex (NL).

Country:  Great Britain (UK)
Manufacturer / Brand:  Roberts Radio Co.Ltd., East Molesey, Surrey, UK
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH3 EF9 EBC3 EL3 AZ1 or AZ2
Main principle Superheterodyne (common); ZF/IF 430 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: M5A - Roberts Radio Co.Ltd., East
Material Leather / canvas / plastic - over other material
Shape Tablemodel, with any shape - general.
Notes

Portable superhet AC mains receiver with carrying handle on top. Released July 1939.

Mentioned in The Wireless and Electrical Trader
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (457)

Model page created by Howard Craven. See "Data change" for further contributors.



All listed radios etc. from Roberts Radio Co.Ltd., East Molesey, Surrey, UK
Here you find 82 models, 78 with images and 43 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
