Revival R250

Revival R250; Roberts Radio Co.Ltd (ID = 1016154) Radio Revival R250; Roberts Radio Co.Ltd (ID = 1016156) Radio
Revival R250; Roberts Radio Co.Ltd (ID = 1069018) Radio Revival R250; Roberts Radio Co.Ltd (ID = 2629875) Radio
Revival R250; Roberts Radio Co.Ltd (ID = 2637109) Radio Revival R250; Roberts Radio Co.Ltd (ID = 2637110) Radio
Revival R250; Roberts Radio Co.Ltd (ID = 2637111) Radio
Use red slider bar for more.
Revival R250; Roberts Radio Co.Ltd (ID = 1016154) Radio
Roberts Radio Co.Ltd: Revival R250 [Radio] ID = 1016154 933x767
Select picture or schematic to display from thumbnails on the right and click for download.
For model Revival R250, Roberts Radio Co.Ltd., East Molesey, Surrey, UK:
This is my own picture from my radio collection and is o/k to publish.

Country:  Great Britain (UK)
Manufacturer / Brand:  Roberts Radio Co.Ltd., East Molesey, Surrey, UK
Year: 1995–2011 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Batteries / addl. power jack / 9 Volt
Loudspeaker Ø 2.75 inch = 7 cm
Power out
from Radiomuseum.org Model: Revival R250 - Roberts Radio Co.Ltd., East
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 9 x 6 x 3.75 inch / 229 x 152 x 95 mm
Notes

The Roberts R250 portable radio in a rexine covered MDF case available in various colours with a matching carrying handle over the top and with a guilt speaker mesh on the front measuring 6.5 inches long x 3 inches high. The acrylic dial is positioned between the volume/on off knob on the top left hand side and the tuner knob on the right hand side, and the name 'Roberts' is printed behind the tone, FM,MW and LW cream coloured push buttons.. The cabinet design is based on the 1960 Roberts R200 model.

See also Revival (retro model) R250.

Net weight (2.2 lb = 1 kg) 1.560 kg / 3 lb 7 oz (3.436 lb)

Model page created by Ron Kendall. See "Data change" for further contributors.
