For model Lausitz 2002 CCIR, Robotron-Elektronik Hoyerswerda, VEB; Hoyerswerda (Ostd.):
Foto hat Uwe fürs RM zur Verfügung gestellt. Vielen Dank

Country:  Germany
Manufacturer / Brand:  Robotron-Elektronik Hoyerswerda, VEB; Hoyerswerda (Ostd.)
Year: 1980–1984 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 3: SF235 SF235 SF225 A281 A211D SAL41 SAY20
Main principle Superheterodyne (common); ZF/IF 455 kHz; 1 AF stage(s)
Tuned circuits 4 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Lausitz 2002 [CCIR] - Robotron-Elektronik
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 335 x 110 x 175 mm / 13.2 x 4.3 x 6.9 inch
Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Price in first year of sale 345.00 DM
Source of data Radiokatalog Band 2, Ernst Erb

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
