Polyskop SWOB 5 BN 333.0019.52

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645363) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645364) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645365) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645366) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645367) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645368) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645369) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645370) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645371) Equipment

Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1645372) Equipment
Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1431756) Equipment Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1431757) Equipment
Use red slider bar for more.
Polyskop SWOB 5 BN 333.0019.52; Rohde & Schwarz, PTE (ID = 1431756) Equipment
Rohde & Schwarz, PTE: Polyskop SWOB 5 BN 333.0019.52 [Equipment] ID = 1431756 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model Polyskop SWOB 5 BN 333.0019.52, Rohde & Schwarz, PTE; München

Country:  Germany
Manufacturer / Brand:  Rohde & Schwarz, PTE; München
alternative name

Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz
Year: 1980 ?? Category: Service- or Lab Equipment
Valves / Tubes 1:
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 110; 125; 220; 235 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Polyskop SWOB 5 BN 333.0019.52 - Rohde & Schwarz, PTE; München
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 484 x 328 x 436 mm / 19.1 x 12.9 x 17.2 inch
Notes

Das Rohde & Schwarz Polyskop SWOB5 ist ein Wobbelmeßplatz für den Frequenzbereich 0,1 - 1000 MHz, 50 Ohm.

Ausgangsspannung Generator von 0 bis -70 dB in 1 dB-Stufen einstellbar, Generatorfrequenz in 4 Stufen einstellbar, 2 horizontale Messlinien, wahlweise logarithmischer Verstärkereinschub E1 (BN 333.5610.02),  logarithmischer Verstärkereinschub E3 (BN 349.3512.02), oder linearer Verstärkereinschub E2 (BN 333.5010.02).

Siehe auch die Ausführungen BN 333.0019.53 (0,1 - 1300 MHz, 50 Ohm) und BN 333.0019.72 (0,1 - 1000 MHz, 75 Ohm).

Net weight (2.2 lb = 1 kg) 25 kg / 55 lb 1.1 oz (55.066 lb)
Collectors' prices
Source of data -- Original prospect or advert
Mentioned in -- Original-techn. papers.
