Semitest V TGP IN 220.7090.02
Rohde & Schwarz, PTE; München
- Country
- Germany
- Manufacturer / Brand
- Rohde & Schwarz, PTE; München
- Year
- 1972 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 197196
-
- alternative name: Messgerätebau Memmingen || Physikalisch-Technisches Entwicklungslabor Dr. Rohde & Dr. Schwarz
Semitest V ohne Programmstecker
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / 4 x 9 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Semitest V TGP IN 220.7090.02 - Rohde & Schwarz, PTE; München
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 199 x 152 x 62 mm / 7.8 x 6 x 2.4 inch
- Notes
- Transistor- und Dioden/Z-Diodentester.
- Net weight (2.2 lb = 1 kg)
- 1.1 kg / 2 lb 6.8 oz (2.423 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Marc Gianella. See "Data change" for further contributors.
