For model 740A, RR Radio (R.R. Radio); Bruxelles, Anderlecht:
Bild aus 1937 Prospekt

Country:  Belgium
Manufacturer / Brand:  RR Radio (R.R. Radio); Bruxelles, Anderlecht
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 58 57 2A5 80
Main principle TRF with regeneration
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: 740A - RR Radio R.R. Radio; Bruxelles
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 380 x 425 x 290 mm / 15 x 16.7 x 11.4 inch
Net weight (2.2 lb = 1 kg) 11.5 kg / 25 lb 5.3 oz (25.33 lb)
Price in first year of sale 875.00 BEF
Source of data Manuel de la Radio 1940, van Cortenberghe

Model page created by Georges Van Campenhout. See "Data change" for further contributors.



All listed radios etc. from RR Radio (R.R. Radio); Bruxelles, Anderlecht
Here you find 111 models, 66 with images and 10 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
