Cassettenrecorder 321G
Use red slider bar for more.
SABA; Villingen: Cassettenrecorder 321G [R-Player] ID = 303289 833x700
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
Brand
|
Schwer & Söhne, GmbH | ||||
|---|---|---|---|---|---|
| Year: 1971/1972 | Category: Sound/Video Recorder and/or Player | ||||
| Semiconductors (the count is only for transistors) | 8: 2SA203 2SB22 2SB186 2SB187 2SB303 2SB303 2SB405 2SB405 |
| Main principle | Audio-Amplification |
|---|---|
| Wave bands | - without |
| Details | Cassette-Recorder or -Player |
| Power type and voltage | Line / Batteries (any type) / 220 / 4 x 1,5 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.5 cm = 4.1 inch |
| Power out | 1 W (unknown quality) |
| from Radiomuseum.org | Model: Cassettenrecorder 321G - SABA; Villingen |
| Material | Plastics (no bakelite or catalin) |
| Shape | Portable set > 8 inch (also usable without mains) |
| Dimensions (WHD) | 260 x 165 x 75 mm / 10.2 x 6.5 x 3 inch |
| Notes | |
| Net weight (2.2 lb = 1 kg) | 2.5 kg / 5 lb 8.1 oz (5.507 lb) |
| Price in first year of sale | 228.00 DM |
| External source of data | Erb |
| Source of data | Handbuch VDRG 1971/1972 |
