2SA203

Information - Help
ID = 38929

Country:
Japan
Brand: Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Tube type:  Transistor   RF/IF-Stage
Identical to 2SA203
Similar Tubes
Normally replaceable-slightly different:
  AF127 ; OC45

Base Wires
Filament Solid State
Description PNP germanium alloy transistor intended as AM IF amplifier.

Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
6 x 10 x mm / 0.24 x 0.39 x inch
Weight 1 g / 0.04 oz
Literature

2SA203: eigene Arbeit
Karl-Heinz Entrich


2SA203: TTT Steidle 1981
Günther Stabe



Usage in Models 1= 1959 ; 4= 1960?? ; 4= 1960? ; 1= 1961?? ; 2= 1961? ; 1= 1961 ; 2= 1962?? ; 4= 1962? ; 6= 1963?? ; 3= 1963? ; 1= 1964?? ; 2= 1964 ; 9= 1965?? ; 7= 1965? ; 1= 1965 ; 1= 1966?? ; 7= 1966? ; 4= 1967?? ; 7= 1967? ; 3= 1967 ; 2= 1968?? ; 5= 1968? ; 3= 1968 ; 2= 1969?? ; 1= 1969? ; 2= 1969 ; 4= 1970?? ; 3= 1970? ; 2= 1970 ; 1= 1971? ; 1= 1971 ; 2= 1972?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):98
