HiFi-Studio 8050 Stereo G Mod. St 8050 G

HiFi-Studio 8050 Stereo G Mod. St 8050 G; SABA; Villingen (ID = 1818652) Radio HiFi-Studio 8050 Stereo G Mod. St 8050 G; SABA; Villingen (ID = 1932201) Radio
HiFi-Studio 8050 Stereo G Mod. St 8050 G; SABA; Villingen (ID = 1932210) Radio HiFi-Studio 8050 Stereo G Mod. St 8050 G; SABA; Villingen (ID = 1932211) Radio
HiFi-Studio 8050 Stereo G Mod. St 8050 G; SABA; Villingen (ID = 1932212) Radio
Use red slider bar for more.
HiFi-Studio 8050 Stereo G Mod. St 8050 G; SABA; Villingen (ID = 1818652) Radio
SABA; Villingen: HiFi-Studio 8050 Stereo G Mod. St 8050 G [Radio] ID = 1818652 933x292
Select picture or schematic to display from thumbnails on the right and click for download.
For model HiFi-Studio 8050 Stereo G Mod. St 8050 G, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1971/1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 55:
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 8 AM circuit(s)     14 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: HiFi-Studio 8050 Stereo G Mod. St 8050 G - SABA; Villingen
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 605 x 135 x 315 mm / 23.8 x 5.3 x 12.4 inch
Notes

HiFi-Stereo-Steuergerät. NF-Verstärker mit 2 Endstufen je 15 W (Sinus). 4 schaltbere Lautsprecherausgänge. Frequenzbereiche: UKW 88..104 MHz, KW 6..10,5 MHz, MW 520..1600 kHz, LW 150..350 kHz. 5 FM-Fixtasten. Signalanzeige über Instrument. Eingang: TA (magn./ krist.) und Tonbandgerät. Filter: Rausch / Rumpel / Linear. Schieberegler für Lautstärke, Balance, Höhen und Tiefen. Kopfhörer-Ausgang auf Frontplatte (Würfelstecker).
Gehäuse: Nussbaum, naturhell oder mattweiss.

Diskret aufgebauter Stereo-Decoder. Weisse Skala.

Siehe auch HiFi-Studio 8050 H mit 50 Transistoren, IC-Stereo-Decoder und grüner Skala.

Net weight (2.2 lb = 1 kg) 10.5 kg / 23 lb 2 oz (23.128 lb)
Price in first year of sale 828.00 DM
Collectors' prices
External source of data Erb
Source of data Handbuch VDRG 1971/1972
