Schauinsland T168L

Schauinsland T168L; SABA; Villingen (ID = 529024) Television Schauinsland T168L; SABA; Villingen (ID = 2044099) Television
Use red slider bar for more.
Schauinsland T168L; SABA; Villingen (ID = 529024) Television
SABA; Villingen: Schauinsland T168L [Television] ID = 529024 888x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Schauinsland T168L, SABA; Villingen:
Funktechnik 14. 1965

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1965/1966 Category: Television Receiver (TV) or Monitor
Valves / Tubes 12: A65-11W
Semiconductors (the count is only for transistors) 6:
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Schauinsland T168L - SABA; Villingen
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 690 x 520 x 310 mm / 27.2 x 20.5 x 12.2 inch
Notes VHF/UHF.
Net weight (2.2 lb = 1 kg) 32.5 kg / 71 lb 9.4 oz (71.586 lb)
Source of data Handbuch VDRG 1965/1966

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
