Schauinsland T196D electronic

Schauinsland T196D electronic; SABA; Villingen (ID = 696920) Television

Schauinsland T196D electronic; SABA; Villingen (ID = 696922) Television

Schauinsland T196D electronic; SABA; Villingen (ID = 696924) Television

Schauinsland T196D electronic; SABA; Villingen (ID = 2048504) Television

Schauinsland T196D electronic; SABA; Villingen (ID = 2048521) Television
Schauinsland T196D electronic; SABA; Villingen (ID = 2048468) Television Schauinsland T196D electronic; SABA; Villingen (ID = 2048469) Television
Schauinsland T196D electronic; SABA; Villingen (ID = 2048501) Television Schauinsland T196D electronic; SABA; Villingen (ID = 2048503) Television
Use red slider bar for more.
Schauinsland T196D electronic; SABA; Villingen (ID = 2048468) Television
SABA; Villingen: Schauinsland T196D electronic [Television] ID = 2048468 850x630
Select picture or schematic to display from thumbnails on the right and click for download.
For model Schauinsland T196D electronic, SABA; Villingen:
Q: Saba, Service-Unterlagen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1968 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 8: EF85 PFL200 PCL805 PCH200 PCF802 PL504 PL95 A65-11W
Semiconductors (the count is only for transistors) 11:
Main principle Super-Heterodyne (Super in general); ZF/IF 38900/33400/5500 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Schauinsland T196D electronic - SABA; Villingen
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 750 x 520 x 430 mm / 29.5 x 20.5 x 16.9 inch
Notes

Empfangsbereiche
VHF - Bereich Kanäle 2 - 12
UHF - Bereich Kanäle 21 - 60
Antenneneingang 240 Ohm symmetrisch

Anschluss für Kabelfernbedienung FS18.

Net weight (2.2 lb = 1 kg) 30 kg / 66 lb 1.3 oz (66.079 lb)
Literature/Schematics (1) Schematic

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
