Schauinsland T2600 Color F

Schauinsland T2600 Color F; SABA; Villingen (ID = 338350) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338351) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338352) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338353) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338354) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338355) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338356) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338357) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338358) Television

Schauinsland T2600 Color F; SABA; Villingen (ID = 338359) Television
Schauinsland T2600 Color F; SABA; Villingen (ID = 2354448) Television Schauinsland T2600 Color F; SABA; Villingen (ID = 2354447) Television
Schauinsland T2600 Color F; SABA; Villingen (ID = 2354450) Television Schauinsland T2600 Color F; SABA; Villingen (ID = 2354449) Television
Schauinsland T2600 Color F; SABA; Villingen (ID = 337783) Television Schauinsland T2600 Color F; SABA; Villingen (ID = 337784) Television
Schauinsland T2600 Color F; SABA; Villingen (ID = 337785) Television Schauinsland T2600 Color F; SABA; Villingen (ID = 337643) Television
Schauinsland T2600 Color F; SABA; Villingen (ID = 337786) Television Schauinsland T2600 Color F; SABA; Villingen (ID = 337787) Television
Use red slider bar for more.
Schauinsland T2600 Color F; SABA; Villingen (ID = 2354448) Television
SABA; Villingen: Schauinsland T2600 Color F [Television] ID = 2354448 1000x645
Select picture or schematic to display from thumbnails on the right and click for download.
For model Schauinsland T2600 Color F, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1970/1971 Category: Television Receiver (TV) or Monitor
Valves / Tubes 11: PCL805 PCF802 PY500 PL509 PC92 PC92 EF80 EF183 PL802 PL95 A67-100X
Semiconductors (the count is only for transistors) 32:
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Schauinsland T2600 Color F - SABA; Villingen
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 795 x 525 x 575 mm / 31.3 x 20.7 x 22.6 inch
Notes 3 ICs.
Wellenbereiche: VHF-Kanäle 2-12, UHF-Kanäle 21-60.
Net weight (2.2 lb = 1 kg) 45 kg / 99 lb 1.9 oz (99.119 lb)
Price in first year of sale 2'398.00 DM
Collectors' prices
Source of data Handbuch VDRG 1970/1971
Mentioned in -- Original prospect or advert
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Heinz Westerweller. See "Data change" for further contributors.
