Schauinsland Telecomputer T 244 H
SABA; Villingen
- Country
- Germany
- Manufacturer / Brand
- SABA; Villingen
- Year
- 1973/1974
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 129524
-
- Brand: Schwer & Söhne, GmbH
Weiler Katalog 1973
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Number of Transistors
- 20
- Semiconductors
- BC148 BF196 BF197 AF254 AF256 AF139 AF239 BF257 BF258 BC261 BC170 BC171 BC172 BC212 BC251 BC237 MJE340 BC204 SE4020 ZTK33 TAA550 SAS560 SAS570 TBA120
- Main principle
- Superhet with RF-stage; ZF/IF 38900/33400/5500 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Schauinsland Telecomputer T 244 H - SABA; Villingen
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 700 x 480 x 425 mm / 27.6 x 18.9 x 16.7 inch
- Notes
-
61 cm Tischgerät, 20 Transistor, 5 IC´s, 51 Dioden, 5 Röhren, VHF/UHF-Tuner, beleuchtete Programmanzeige, Fernsteuerung FS 40.
Elliptischer Lautsprecher 17 x 11,5 cm.
- Net weight (2.2 lb = 1 kg)
- 27 kg / 59 lb 7.5 oz (59.471 lb)
- Mentioned in
- -- Original-techn. papers. (Weiler Angebot 1973/74)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Karlheinz Fischer. See "Data change" for further contributors.
