For model Desconocido - Unknown, SAICA (marca)

Country:  Spain
Manufacturer / Brand:  SAICA (marca)
Year: 1950 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 435 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: Desconocido - Unknown - SAICA marca
Material Wooden case
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 280 x 200 x 160 mm / 11 x 7.9 x 6.3 inch

Model page created by Juan Jose Roncal. See "Data change" for further contributors.



All listed radios etc. from SAICA (marca)
Here you find 2 models, 2 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
