Salorita 3A

Salora; Salo

  • Year
  • 1969 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 182244

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 10
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Dry Batteries / 6 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Salorita 3A - Salora; Salo
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 275 x 170 x 80 mm / 10.8 x 6.7 x 3.1 inch
  • Notes
  • See also Derby Junior which is a "Blaupunkt" branded Salora Salorita 3A model.

  • Net weight (2.2 lb = 1 kg)
  • 1.7 kg / 3 lb 11.9 oz (3.744 lb)
  • Literature/Schematics (1)
  • -- Schematic
  • Author
  • Model page created by Jouko Laukkanen. See "Data change" for further contributors.
