• Country
• Japan

• Manufacturer / Brand
• Sansei Electronics Corp (SEC).; Tokyo

• Year
• 1983

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 154697

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors

• Details
• Loudspeaker + integr.Amplifier

• Power type and voltage
• Storage and/or dry batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch

• Power out
• 0.2 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Signal Tracer/Injector 6100 - Sansei Electronics Corp SEC.;

• Dimensions (WHD)
• 160 x 50 x 106 mm / 6.3 x 2 x 4.2 inch

• Notes
• VU meter: 100uA. Tracer: Input impedance 100K ohms. Gain: 60dB at 1KHz. Attenuation: Ranges 0;20;40;60dB. Injector: Square wave 1KHz. Max. input 400V. Output level: 0 ~ 4,5V p-p.

• Net weight (2.2 lb = 1 kg)
• 0.470 kg / 1 lb 0.6 oz (1.035 lb)

• Author
• Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
