AM/FM Stereo Tuner Amplifier 220

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227034) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227027) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227029) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227028) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227030) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227031) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227032) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227033) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227035) Radio

AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1227036) Radio
AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 818975) Radio AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 818957) Radio
AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 818959) Radio AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 818964) Radio
AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 818970) Radio AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 818977) Radio
AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 818985) Radio AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 1607396) Radio
Use red slider bar for more.
AM/FM Stereo Tuner Amplifier 220; Sansui Electric Co., (ID = 818975) Radio
Sansui Electric Co.,: AM/FM Stereo Tuner Amplifier 220 [Radio] ID = 818975 900x657
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM/FM Stereo Tuner Amplifier 220, Sansui Electric Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Sansui Electric Co., Ltd.; Tokyo
Year: 1973 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 12: ECC85 EF93 EF93 EF93 6E5 EK90 ECC83 ECC85 ECL82 ECL82 ECL82 ECL82
Semiconductors (the count is only for transistors) 2: 2SC402 2SC402
Main principle Superheterodyne (common)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: AM/FM Stereo Tuner Amplifier 220 - Sansui Electric Co., Ltd.;
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 445 x 150 x 350 mm / 17.5 x 5.9 x 13.8 inch
Notes AM/FM Tuner amplifier, RMS Stereo power 8 w x 2, Output impedance 8 and 16 Ohms,Imput sensitivity Phono 3 mV,Aux 1 and 2- 150 mV, Tape monitor 660 mV, - Bass 50 Hz + 10 db to - 10 db, Treble 10.000 Hz + 10 db to - 10 db, Loudness 50 Hz + 8 db, 10.000 Hz + 8 db (Volume control at - 30 db) Noise filter 10.000 Hz -10 db, Mode Stereo and Mono, Selector - Phone-SW-MW-Aux1-Aux2, FM 88~108 MHz, AM 535~1605 KHz,SW 3.9~12 MHz, Eye tube tuning, AFC Switch, Power consumption 106 VA - Silicon transistors 2SC-402 x 2, Silicon diodes OA-91 x 3
Net weight (2.2 lb = 1 kg) 13.2 kg / 29 lb 1.2 oz (29.075 lb)
Collectors' prices
Source of data - - Data from my own collection
Literature/Schematics (1) - - Manufacturers Literature

Model page created by J. Virgilio Santos. See "Data change" for further contributors.



All listed radios etc. from Sansui Electric Co., Ltd.; Tokyo
Here you find 376 models, 363 with images and 113 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
