• Country
• Japan

• Manufacturer / Brand
• Sansui Electric Co., Ltd.; Tokyo

• Year
• 9999

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 105419

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Dublette mit ID = 235732 - Sansui Electric Co., Ltd.;

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 430 x 135 x 260 mm / 16.9 x 5.3 x 10.2 inch

• Notes
• AM/FM-Stereo-Tuner mit Dolby FM/4-Kanal-Adapter-Anschluss.

• Net weight (2.2 lb = 1 kg)
• 6.4 kg / 14 lb 1.6 oz (14.097 lb)

• Author
• Model page created by Peter Böhm. See "Data change" for further contributors.
