7S-P6

7S-P6; Sanyo Electric Co. (ID = 602893) Radio
7S-P6; Sanyo Electric Co. (ID = 2122108) Radio 7S-P6; Sanyo Electric Co. (ID = 2122109) Radio
7S-P6; Sanyo Electric Co. (ID = 2122110) Radio 7S-P6; Sanyo Electric Co. (ID = 2122111) Radio
7S-P6; Sanyo Electric Co. (ID = 1811601) Radio 7S-P6; Sanyo Electric Co. (ID = 908230) Radio
7S-P6; Sanyo Electric Co. (ID = 1811602) Radio 7S-P6; Sanyo Electric Co. (ID = 1811603) Radio
7S-P6; Sanyo Electric Co. (ID = 682069) Radio 7S-P6; Sanyo Electric Co. (ID = 1811604) Radio
Use red slider bar for more.
7S-P6; Sanyo Electric Co. (ID = 2122108) Radio
Sanyo Electric Co.: 7S-P6 [Radio] ID = 2122108 1000x627
Select picture or schematic to display from thumbnails on the right and click for download.
For model 7S-P6, Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Country:  Japan
Manufacturer / Brand:  Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Year: 1960 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: 2SA60 2SA202 2SA203 2SB185 2SB186 2SB187 2SB187
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 7S-P6 - Sanyo Electric Co. Ltd.;
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 151 x 940 x 450 mm / 5.9 x 37 x 17.7 inch
Notes 'Personal All-wave; Transistor 7'
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.
