All Wave Deluxe 8U-604N

All Wave Deluxe 8U-604N; Sanyo Electric Co. (ID = 521841) Radio All Wave Deluxe 8U-604N; Sanyo Electric Co. (ID = 521842) Radio
All Wave Deluxe 8U-604N; Sanyo Electric Co. (ID = 521843) Radio All Wave Deluxe 8U-604N; Sanyo Electric Co. (ID = 1439781) Radio
All Wave Deluxe 8U-604N; Sanyo Electric Co. (ID = 1439782) Radio All Wave Deluxe 8U-604N; Sanyo Electric Co. (ID = 1439783) Radio
All Wave Deluxe 8U-604N; Sanyo Electric Co. (ID = 1439784) Radio
Use red slider bar for more.
All Wave Deluxe 8U-604N; Sanyo Electric Co. (ID = 521841) Radio
Sanyo Electric Co.: All Wave Deluxe 8U-604N [Radio] ID = 521841 933x668
Select picture or schematic to display from thumbnails on the right and click for download.
For model All Wave Deluxe 8U-604N, Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Country:  Japan
Manufacturer / Brand:  Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Year: 1960 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: OC170 OC45 OC45 OC72 OC71 OC71 OC72 OA79
Main principle Superheterodyne (common)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out
from Radiomuseum.org Model: All Wave Deluxe 8U-604N - Sanyo Electric Co. Ltd.;
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 235 x 150 x 70 mm / 9.3 x 5.9 x 2.8 inch

Model page created by Francisco Gallego. See "Data change" for further contributors.
