Super Ondolina 533A2; SBR Société Belge (ID = 113464) Radio
SBR Société Belge: Super Ondolina 533A2 [Radio] ID = 113464 450x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super Ondolina 533A2, SBR Société Belge Radio-Electrique, Bruxelles

Country:  Belgium
Manufacturer / Brand:  SBR Société Belge Radio-Electrique, Bruxelles
Year: 1932/1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: MS4B or E452T MHL4 MS4B or E452T MS4B or E452T PT4N U10 or 506 or RGN1054
Main principle Super-Heterodyne (Super in general); ZF/IF 123 kHz; Anode bend detection
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 140; 220; 245 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Super Ondolina 533A2 - SBR Société Belge Radio-
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Dimensions (WHD) 450 x 450 x 280 mm / 17.7 x 17.7 x 11 inch
Notes
  • This superheterodyne radio works on a simple wire antenna, where previous SBR superheterodyne models worked with a loop antenna.
  • Tuning scales with names and wavelenghts are standard from now on.
  • SBR produced the following models 533:
    • 533x1: table model without loudspeaker;
    • 533x2: table model with loudspeaker;
    • 533x3: luxury console;
    • 533x4: luxury console with pick-up;

where 'x' represents 'A' (AC mains) or 'C' (DC mains, 110 or 220V).

Price in first year of sale 3,100.00 BFr
Collectors' prices
External source of data P.H. Brans

Model page created by Hugo Sneyers. See "Data change" for further contributors.
