- Country
- Belgium
- Manufacturer / Brand
- SBR Société Belge Radio-Electrique, Bruxelles
- Year
- 1965 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 76316
service doc.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 28
- Semiconductors
- AF121 AF125 AC126 AC172 AC125 AC132 AC127 AC128 AF102 BY114 BZY59 BZY61 AA119 BA114 OA200 BA102
- Main principle
- Superheterodyne (common); ZF/IF 452/10700 kHz; 5 AF stage(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 145; 165; 220; 245 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 4 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: R26 - SBR Société Belge Radio-
- Shape
- Tablemodel with Push Buttons.
- Notes
-
AM radio with built-in ferroceptor:
- LW: 150 - 400 kHz.
- BC: 517 - 1622 kHz.
- SW: 5,9 - 18,2 MHz.
FM stereo radio with dipole antenna input: 87,5 - 108 MHz.
Dial lamps: 2 x 6.3V / 300mA + FM stereo indicator lamp: 6V / 50 mA.
Remark: The semiconductor transistors and diodes are listed only once. For details see schematic.
