Weekend 80 Automatik 120167

Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93112) Radio

Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93113) Radio

Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93114) Radio

Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93115) Radio

Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93116) Radio

Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93118) Radio

Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93117) Radio

Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93111) Radio
Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93110) Radio Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 1458558) Radio
Use red slider bar for more.
Weekend 80 Automatik 120167; Schaub und Schaub- (ID = 93110) Radio
Schaub und Schaub-: Weekend 80 Automatik 120167 [Radio] ID = 93110 504x409
Select picture or schematic to display from thumbnails on the right and click for download.
For model Weekend 80 Automatik 120167, Schaub und Schaub-Lorenz

Country:  Germany
Manufacturer / Brand:  Schaub und Schaub-Lorenz
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF106 AF125 AF136 AF137 AF138 AC122 AC122 AC117 AC117
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Weekend 80 Automatik 120167 - Schaub und Schaub-Lorenz
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 280 x 170 x 80 mm / 11 x 6.7 x 3.1 inch
Notes Betrieb im Auto über Autohalterung aus 6-V- oder 12-V-Autobatterie, dann NF-Ausgangsleistung = 2,5 W; Netzbetrieb mit zusätzlichem Netzteil möglich.
1201-67 = perlweiß.
Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Collectors' prices
Mentioned in Handbuch VDRG 1967/1968
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Egon Penker. See "Data change" for further contributors.
