• Country
• France

• Manufacturer / Brand
• Schneider (Frères, Radio-Télévision); Paris, Ivry / Seine

• Year
• 1949 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 121169

• Number of Tubes
• 5

• Valves / Tubes
• ECH3 ECF1 EBL1 1883 6AF7 or EM4

• Main principle
• Superheterodyne (common); ZF/IF 475 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch

• Power out
• 4 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: SF157 [bakélite] - Schneider Frères, Radio-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 495 x 290 x 240 mm / 19.5 x 11.4 x 9.4 inch

• Author
• Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.

• Other Models

• Here you find 262 models, 215 with images and 134 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
