• Country
• Germany

• Manufacturer / Brand
• Schneider-Opel AG, Radiowerke; Frankfurt a.M., später Berlin

• Year
• 1928–1930

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 16942

• • Brand: Mars

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• RE084 RE084 RE134

• Main principle
• TRF with regeneration; 2 AF stage(s)

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Phönix I SO PH1 [3 Röhren] - Schneider-Opel AG, Radiowerke;

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 190 x 190 x 182 mm / 7.5 x 7.5 x 7.2 inch

• Notes

• Sch in [638540]

  Spulenkoppler eingebaut, von aussen bedienbar.

  Siehe auch Schneider-Opel Phönix I SO PH1 mit TeKaDe 3-fach Röhre VT139

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Literature/Schematics (1)
• -- Schematic
